Specs, dilutions, and documents in one place.
Dilution rates, the brewery CIP/SIP sequence, the refrigeration descaling protocol, source tables, and the documents procurement needs to sign off.
Pull a document, price the job, or match a replacement.
Browse the reference tables, or jump straight to pricing or a replacement match.
Open the technical reference Dilution rates, CIP sequence, refrigeration protocol, tank-cleaning field test, corrosion tables, and confirmed segment pricing links.
Dilution numbers buyers ask for first.
Representative ratios, written as parts water to 1 part concentrate. Always confirm against the product label and site conditions before use.
| Product | Light duty | Moderate | Heavy / severe |
|---|---|---|---|
| VertKleen HCR | 10:1 | 5:1 | 2:1 to 1:1 (injection / pipe) |
| VertKleen CR | 10:1 | 5:1 | 2:1 |
| VertKleen CR HD | 100:1 glass, 30:1 floors | 10:1 hoods | 5:1 heavy oil |
| VertKleen MultiWash | 100:1 windows | 30:1 exterior | 4:1 to 10:1 moss, 2:1 severe |
| VertKleen LAM3 | 10:1 | 5:1 | 1 cup / 50 gal pond algae |
| Purgo | 64:1 non-food | 32:1 food-contact | 10:1 mold, 100 ppm tower |
| VertKleen AlumiBrite | 10:1 | 5:1 | 1:1 |
| VertKleen Torque | 20:1 new | 15:1 | 5:1 to 10:1 heavy |
The CR then HCR brewery sequence.
CR then HCR, proven across seven Florida breweries and Loaded Cannon Distillery on tanks and heat exchangers.
Hot-water pre-rinse
Flush with hot water at 140 to 180 °F to clear loose solids before chemical contact.
CR alkaline wash
About 10 to 12 L of CR per 100 gal hot water, circulate or jet 30 to 40 minutes. Dissolves yeast, protein, fat, biofilm, and beer-stone. Produces no CO₂, so no carbonate forms. Dump and hot-water rinse.
HCR acid wash
About 8 to 10 L of HCR per 100 gal hot water, circulate 30 minutes. Dissolves inorganic scale, calcium, and rust. Final sanitation requirements remain label- and site-protocol dependent.
Final rinse and verify
Hot-water rinse and confirm the rinse runs back at pH 6.5 to 8.5 before returning the vessel to service.
Descaling protocol that protects the charge.
Source: Walmart OEM refrigeration descaling case study. Protects aluminum, copper, steel, and stainless; low-foam recirculation.
The cold-storage walkdown checklist.
The on-site assessment framework used at a Walmart perishable distribution center. Every zone is checked for the buildup that drives energy and labor cost, then matched to a core product or footnoted program component.
| Zone | What we check on site |
|---|---|
| Banana and produce rooms | Mildew, mold, and condensation |
| Refrigerated sections | Hard-to-reach surface cleaning |
| Ammonia coils and plumbing | Scale and descaling, chloride-free |
| Condenser, coil, and drain lines | Buildup and flow restriction |
| Kitchen, break areas, and grease traps | Heavy degreasing |
| Safety, storage, and pilot readiness | Compliance and 0-0-0 handling |
Source: Walmart perishable DC on-site maintenance assessment.
Source tables you can copy, not screenshots.
Selectable HTML rebuilt from the original charts and tables, so you can paste a number straight into a quote or a spec.
Cooling tower traditional chemistry vs. VertKleen
| Function | Traditional chemistry | Traditional HMIS | VertKleen equivalent | VertKleen HMIS |
|---|---|---|---|---|
| Scale & corrosion inhibitor | Phosphate / zinc / molybdate blends | 1-2 | WaterSafe60, no heavy metals | 0-0-0 |
| Oxidizing biocide | Stabilized bromine / sodium hypochlorite | 3-0-1 | Purgo, FIFRA 25(b) minimum-risk | 0-0-0 |
| Non-oxidizing biocide | Glutaraldehyde 50% | 3-2-0 | DBNPA tablet, controlled release, one tab per quarter | Low |
| Acid clean / passivation | Hydrochloric / inhibited acids | 3-0-1 | VertKleen HCR, biodegradable acid replacement | 0-0-0 |
| pH adjustment / caustic | Caustic soda / sodium hydroxide | 3-0-1 | VertKleen CR, caustic replacement and pH adjuster | 0-0-0 |
| Degreaser / cleaner | Caustic / solvent degreasers | 2-1 | VertKleen Neutral, neutral pH-7 degreaser | 0-0-0 |
Source: cooling tower traditional-vs-VertKleen table. DBNPA remains the program's mild-hazard exception.
Descaler vs. conventional acids
| Acid / descaler | pH | Dissolve rate | Corrosion | Hazard pictograms |
|---|---|---|---|---|
| VertKleen Descaler | 0 | 9.8 | 0.59 mpy | None |
| Hydrochloric (HCl) | 0.5 | 8.9 | 609.5 mpy | 4, Severe |
| Urea HCl | 1.0 | 7.0 | 802.2 mpy | 4, Severe |
| Sulfuric / sulfamic | 1.0 | 6.3 | 520.6 mpy | 3, High |
| Glycolic / gluconic | 3.0 | 1.6 | 402.5 mpy | 3, High |
| Phosphoric | 3.0 | 0.9 | 173.9 mpy | 3, High |
Source: Descaler_vs_acids_corrosion_table.png. Dissolve rate is calcium-carbonate coupon testing; corrosion is mils per year on carbon steel.
Dealership area product and dilution
| Area / application | Product | Key win | Dilution |
|---|---|---|---|
| New / used vehicle wash | Torque | Wash + wax in one step | 15:1 - 20:1 |
| Aluminum wheels and rims | AlumiBrite | HF/HCl-free brightening workflow | 5:1 - 10:1 |
| Engine bay / parts washer | CR HD | Heavy-duty degreaser; aerospace-spec files by request | 5:1 - 10:1 |
| Interior fabric and carpet | MultiWash | Odor-control support | 5:1 |
| Underbody / rust removal | CRS / Descaler family | Non-corrosive HCl replacement | 2:1 - 5:1 |
| HVAC coils / cooling towers | Descaler-family label + MultiWash | Scale + buildup support | 5:1 |
| Showroom and service-bay floors | CR HD | Streak-free, zero residue | 30:1 |
| Restrooms and locker rooms | MultiWash + Purgo | Clean + odor-control support | 5:1 |
| Building exterior / stucco | MultiWash | Drone-application workflow | 2:1 - 5:1 |
| Kitchen / break room | CR HD | Food-adjacent cleaning workflow | 10:1 |
| Odor and bacteria control | Purgo | FIFRA 25(b) minimum-risk | 1:32 - 1:64 |
Source: Dealership_area_product_dilution_table.png. CRS is treated as a descaler-family/source-label reference until SKU ownership is confirmed.
HVAC facility pricing
| Product | Pack | Public price / gal | Public pack price |
|---|---|---|---|
| VertKleen HCR | 1 gal jug | $24.72/gal | $24.72 |
| VertKleen HCR | 2.5 gal jug | $24.72/gal | $61.80 |
| VertKleen Descaler | 1 gal jug | $17.18/gal | $17.18 |
| VertKleen Descaler | 2.5 gal jug | $17.18/gal | $42.94 |
| VertKleen AlumiBrite | 1 gal jug | $13.77/gal | $13.77 |
| VertKleen AlumiBrite | 2.5 gal jug | $13.77/gal | $34.43 |
| VertKleen CR | 1 gal jug | $22.02/gal | $22.02 |
| VertKleen CR | 2.5 gal jug | $22.02/gal | $55.05 |
| VertKleen CR HD | 1 gal jug | $12.12/gal | $12.12 |
| VertKleen CR HD | 2.5 gal jug | $12.12/gal | $30.30 |
| VertKleen MultiWash | 1 gal jug | $16.78/gal | $16.78 |
| VertKleen MultiWash | 2.5 gal jug | $16.78/gal | $41.96 |
| VertKleen Neutral | 1 gal jug | $18.54/gal | $18.54 |
| VertKleen Neutral | 2.5 gal jug | $18.54/gal | $46.36 |
| VertKleen LAM3 | 1 gal jug | $22.21/gal | $22.21 |
| VertKleen LAM3 | 2.5 gal jug | $22.21/gal | $55.52 |
| VertKleen Purgo | 1 gal jug | $21.49/gal | $21.49 |
| VertKleen Purgo | 2.5 gal jug | $21.49/gal | $53.73 |
Source: VertKleen_Website_Pricing_WebDev.xlsx, HVAC & Facilities tab. Open full HVAC pricing Prices valid six months from publication. Shipping and freight excluded — FOB Ex Plant, Merritt Island FL.
Property maintenance pricing
| Product | Pack | Public price / gal | Public pack price |
|---|---|---|---|
| VertKleen HCR | 1 gal jug | $21.63/gal | $21.63 |
| VertKleen HCR | 2.5 gal jug | $21.63/gal | $54.08 |
| VertKleen CR | 1 gal jug | $19.27/gal | $19.27 |
| VertKleen CR | 2.5 gal jug | $19.27/gal | $48.17 |
| VertKleen CR HD | 1 gal jug | $10.61/gal | $10.61 |
| VertKleen CR HD | 2.5 gal jug | $10.61/gal | $26.51 |
| VertKleen Purgo | 1 gal jug | $21.49/gal | $21.49 |
| VertKleen Purgo | 2.5 gal jug | $21.49/gal | $53.73 |
| VertKleen Descaler | 1 gal jug | $15.03/gal | $15.03 |
| VertKleen Descaler | 2.5 gal jug | $15.03/gal | $37.57 |
| VertKleen Neutral | 1 gal jug | $16.23/gal | $16.23 |
| VertKleen Neutral | 2.5 gal jug | $16.23/gal | $40.56 |
| VertKleen MultiWash | 1 gal jug | $14.69/gal | $14.69 |
| VertKleen MultiWash | 2.5 gal jug | $14.69/gal | $36.72 |
| VertKleen LAM3 | 1 gal jug | $22.21/gal | $22.21 |
| VertKleen LAM3 | 2.5 gal jug | $22.21/gal | $55.52 |
Source: VertKleen_Website_Pricing_WebDev.xlsx, Website Price List tab. Open CIP pricing Prices valid six months from publication. Shipping and freight excluded — FOB Ex Plant, Merritt Island FL.
Walmart perishable DSC on-site assessment
| Zone | Assessment prompt | Positioned demo |
|---|---|---|
| Banana rooms | Mildew, mold, and condensation visibility and current product | Purgo + MultiWash spray bottles; photo before and after |
| Refrigerated sections | Hard-to-reach cleaning and shutdown requirements | MultiWash / Purgo spot mildew and odor, no shutdown |
| Ammonia coils and plumbing | Scale, calcium, rust, and current acid | VertKleen Descaler, non-corrosive HCl replacement |
| Condenser, coil, and drain lines | Condenser lines, drain pans, floor drains, chronic blockages | CR HVAC heavy duty, reduced HCl / caustic-soda handling |
| Kitchen, break areas, and grease traps | Current degreaser and pump cadence | CR HD demo on fryer, hood, or floor |
| Safety, storage, and pilot readiness | PPE, storage, spill, and regulatory load | Triple-zero HMIS pilot close |
Source: Walmart_onsite_assessment_1page.png.
Walmart refrigeration descaling results
| System | Protocol | Time | Outcome |
|---|---|---|---|
| Anhydrous ammonia condenser circuit | 15% / ambient | 6-8 hrs | 8-15% compressor energy saving; condensing pressure at design |
| Clean and warm water heating circuits | 10-15% / 40-60 C | 4-6 hrs | 18-24% heating efficiency restored; flow rate up to +30% |
| Aluminum evaporator coils | 10% / ambient | 4-5 hrs | Reported scale removal; no pitting noted; defrost intervals extended |
| Copper tubing and condenser bundles | 15% / ambient | 5-6 hrs | Bright metal; head pressure down; no dezincification |
| Plate heat exchangers | 20% / ambient | 3-4 hrs | 40-60% pressure-drop reduction; up to 94% efficiency restored |
| Shell and tube heat exchangers | 15% / ambient | 6-8 hrs | 3-5 C approach temperature improvement; compressor lift reduced |
Source: Walmart_refrigeration_results_table.png.
Trinidad bunker-fuel tank cleaning test
| Product tested | Application note | Observed result |
|---|---|---|
| VertKleen CR | Sprayed from quart bottle on bunker-fuel residue and wiped immediately; source recommends 15 minute dwell for standard degreaser procedure. | Source report says CR removed dirt and grime with less product use than the butoxyethanol comparator. |
| VertKleen HCR | Poured on the tank wall, then pressure washed immediately after application. | Source report calls HCR the most effective of the three products tested in that experimental setup. |
| Speckleen comparator | Butoxyethanol-base degreaser sprayed 75 times and wiped immediately. | Source report notes oil-residue smudge remained. Speckleen is treated as comparator, not a confirmed VertKleen SKU. |
Source: Trinidad_Tank_Cleaning_Test_CR_HCR_Speckleen.png/PDF. The source itself says no formal procedure was written; publish as field-test evidence, not standardized lab proof.
Carib Brewery lab results
| Measure | VertKleen HCR | CIP acid replaced |
|---|---|---|
| pH | 1.0 | <1 |
| Sample concentration | 7% | 15% |
| Nitrogen (mg/L) | 0 | 33,300 |
| Phosphorus (mg/L) | 0 | 48,950 |
| COD (mg/L) | 0 | 0 |
Source: Carib_brewery_lab_results.png.
The document room.
Download safety data sheets, technical data sheets, and product labels directly — no request form. Certificate-status and program files that are not yet published route through technical review, typically within one business day.
Request additional files.
Documents that route through technical review before release.
Need the document that moves the PO?
Tell the technical team your system, your current chemical, and what you need to get it approved. They will send the right documentation, dilution plan, and pricing.
Ask the technical team
